Standard : SAE J20 R3 Class A

Working Temperature : -60°C to 180 °C

Reinforced layers : 1 ply or 2 plys as customer’s requirement

Standard Color Option : Blue/Red/Black

Other Color Option : Green/Yellow/Orange etc

Length : 10/20/30/50m as customer’s requirement

Product Description :

Silicone heater hoses use in cooling, in heating and air conditioning systems. they are very flexible with good bend radius. This allows it to be used in continuous runs, across the full length of a bus or other long vehicle. With less joints and clips, apart from the associated cost savings, the risk of leakage is greatly reduced.

Specification :

Item	ID	ID	Reinforced layer	Length
Item	(mm)	(inch)	Reinforced layer	(m)
SHH 6	6	1/4"	1 or 2	10/20/30/50/100m etc
SHH 8	8	5/16"	1 or 2	10/20/30/50/100m etc
SHH 10	10	3/8"	1 or 2	10/20/30/50m etc
SHH 13	13	1/2"	1 or 2	10/20/30/50m etc
SHH 16	16	5/8"	1 or 2	10/20/30/50m etc
SHH 19	19	3/4"	1 or 2	10/20/30/50m etc
SHH 22	22	7/8"	1 or 2	10/20/30/50m etc
SHH 25	25	1"	1 or 2	10/20/30/50m etc
SHH 28	28	1 1/8"	1 or 2	10/20/30/50m etc
SHH 30	30	1 1/5"	1 or 2	10/20/30/50m etc
SHH 32	32	1 1/4"	1 or 2	10/20/30/50m etc
SHH 35	35	1 3/8"	1 or 2	10/20/30/50m etc
SHH 38	38	1 1/2"	1 or 2	10/20/30/50m etc

Kindly remind that silicone heater hoses are not used in oil or fuel environment.
